St. Martin’s Episcopal


Schoenstein & Co.
717 Sage Road
Houston, TX 77056

Church Website

ORGAN SPECIFICATIONS

GREAT (4″ Wind)

16′ Gamba 61 Pipes
16′ Bourdon 61
8′ Grand Open Diapason Solo
8′ Open Diapason 61
8′ Harmonic Flute 61
8′ Gamba 12
8′ Bourdon 12
8′ Erzähler 61
8′ Lieblich Gedeckt Choir
8′ Cor Seraphique (II) Swell
4′ Cor Seraphique (II) Swell
4′ Octave Solo
4′ Principal 61
4′ Chimney Flute 61
4′ Silver Flute Choir
22/3′ Twelfth 61
2′ Fifteenth 61
13/5′ Seventeenth 54
2′ Mixture (IV Ranks) 207
16′ Bass Trumpet 12
8′ Trumpet 61
4′ Clarion 61
8′ Tuba Minor Solo
4′ Tuba Clarion Solo
Tremulant (Flutes)
Great Unison Off
8′ Harmonic Trumpet Solo
8′ Tuba Major Solo
Chimes Walker
Cymbelstern Walker

SWELL (42″ Wind)
16′ Lieblich Bourdon 12 Pipes
8′ Open Diapason 61
8′ Stopped Diapason 61
8′ Echo Gamba 61
8′ Gamba Celeste 61
8′ Aeoline Choir
8′ Aeoline Celeste Choir
4′ Gemshorn 61
4′ Harmonic Flute 61
4′ Aeoline Choir
4′ Aeoline Celeste Choir
2′ Flageolet 61
22/3′ Tierce Mixture (III) 183
8′ Flügel Horn 61
8′ French Oboe 61
Tremulant

Stops Under Double Expression
16′ Cor SeraphiqueH 12
8′ Cor Seraphique H 61
8′ Voix Angelique(TC)H49
4′ Cor Seraphique
4′ Voix Angelique
16′ PosauneHH 61
8′ TrumpetHH 61
4′ ClarionHH 61
2′ Quint Mixture (III-V)H 266
8′ Vox HumanaHHH 61
Swell 16′
Swell Unison Off
Swell 4′

CHOIR (42″ Wind)
16′ Aeoline 12 Pipes
8′ Viola Pomposa 61
8′ Viola Celeste 61
8′ Concert Flute 49

Lieblich Gedeckt Bass
8′ Lieblich Gedeckt 61
8′ Aeoline 61
8′ Aeoline Celeste (TC) 49
4′ Fugara 61
4′ Silver Flute 61
22/3′ Nazard 61
22/3′ Twelfth 61
2′ Salicet 61
2′ Harmonic Piccolo 61
13/5′ Tierce (TC) 42
11/3′ Nineteenth 54
1′ Twentysecond 49
16′ Contra Oboe 61
8′ Trumpet 61
8′ Clarinet 61
8′ English Oboe 12
Tremulant
Choir 16′
Choir Unison Off
Choir 4′
8′ Harmonic Trumpet Solo
8′ Tuba Major Solo
Harp Walker
Celesta Walker

SOLO (10″ Wind)
8′ Grand Open
8’ Diapason 61 Pipes
8′ Symphonic Flute 61
8′ Stentor Gamba 61
8′ Gamba Celeste 61
2′ Obbligato Piccolo (TC)
1′ Obbligato Fife 49
8′ French Horn 61
8′ Tuben (III) Swell
Variable Tremulant

Stops Under Double Expression
8′ Viole d=orchestre 61
8′ Viole céleste 61
4′ Octave 61
16′ Corno di Bassetto 61
8′ Tuba Minor 61
8′ Harmonic Trumpet 61
8′ Corno di Bassetto 12
4′ Tuba Clarion 61
Solo 16′
Solo Unison Off
Solo 4′
Orchestral Bells Walker
Chimes Great

Unenclosed Stop
8′ Tuba Major (15″ Wind) 61

PEDAL (42″ Wind)
32′ Diapason (EEEE) 8 Pipes
32′ Sub Bass (72″ Wind) 12
32′ Sub Bass mp
16′ Open Wood 32
16′ Diapason 32
16′ Gamba Great
16′ Sub Bass (72″ Wind) 32
16′ Aeoline Choir
16′ Bourdon Great
16′ Cor Seraphique Swell
16′ Lieblich Bourdon Swell
8′ Open Wood 12
8′ Principal 32
8′ Sub Bass (72″ Wind) 12
8′ Gamba Great
8′ Flute Great
8′ Viola Pomposa Choir
8′ Aeoline Choir
8′ Bourdon Great
8′ Stopped Diapason Swell
4′ Fifteenth 32
4′ Flute Great
4′ Bourdon Great
2′ Flute Great
22/3′ Mixture (III) 96
32′ Contra TromboneH 12
32′ Cornet (Wired)
16′ Trombone H 32
16′ Posaune Swell
16′ Bass Trumpet Great
16′ Contra Oboe Choir
16′ Corno di Bassetto Solo
8′ TrombaH 12
8′ Trumpet Great
8′ Posaune Swell
8′ English Oboe Choir
8′ Clarinet Choir
4′ Clarion* 12
4′ French Oboe Swell
4′ Corno di Bassetto Solo
8′ Pizzicato Bass**
Chimes Great
*Trombone unit in an expression box. 15″ Wind.
**Draws Open Wood at octave pitch through pizzicato touch relay.

COUPLERS
Great to Pedal 8′
Swell to Pedal 8’/4’
Choir to Pedal 8’/4’
Solo to Pedal 8’/4’
Swell to Great 16’/8’/4’
Choir to Great 16’/8’/4’
Solo to Great 16’/8’/4’
Great to Choir 8′
Swell to Choir 16’/8’/4’
Solo to Choir 16’/8’/4’
Pedal to Choir 8′
Choir to Swell 16’/8’/4’
Choir to Solo 8′
Swell to Solo 8′

SPECIAL COUPLERS
Pedal Divide
Swell to Great Sforzando
Solo to Great Sforzando

Note: Pedal Divide deactivates Pedal couplers
notes 1-12 and Pedal stops notes 13-32.
Sforzando couplers are activated by a momentary touch toe lever.

All pipes are new except:
Viole d=orchestre C Hope-Jones
Viole céleste C Hope-Jones
